Lift Capacities (continued) 75C
Boldface italic type indicates hydraulic-limited capacities; lightface type indicates stability-limited capacities, in lb. (kg). Ratings at bucket lift hook; machine equipped with
0.36-cu.-yd. (0.28 m
3 ), 30-in. (750 mm), 522-lb. (237 kg) bucket; and situated on firm, uniform supporting surface. Total load includes weight of cables, hook, etc. Figures do
not exceed 87 percent of hydraulic capacities or 75 percent of weight needed to tip machine. All lift capacities are based on SAE J1097.
Load Point 5 ft. (1.52 m) 10 ft. (3.05 m) 15 ft. (4.57 m) 20 ft. (6.10 m)
Height Over Front Over Side Over Front Over Side Over Front Over Side Over Front Over Side
With 5-ft. 4-in. (1.62 m) arm, 18-in. (450 mm) rubber crawler pads, and blade on ground
10 ft. (3.05 m) 3,831 (1738) 3,831 (1738) 3,272 (1484) 3,093 (1403)
5 ft. (1.52 m) 6,520 (2957) 5,450 (2472) 3,394 (1539) 2,918 (1324)
Ground Line 6,208 (2816) 5,162 (2341) 3,240 (1470) 2,770 (1256)
–5 ft. (–1.52 m) 7,883 (3576) 7,883 (3576) 6,201 (2813) 5,155 (2338) 3,200 (1451) 2,733 (1240)
–10 ft. (–3.05 m) 5,258 (2385) 5,258 (2385)
With 6-ft. 11-in. (2.12 m) arm, 18-in. (450 mm) rubber crawler pads, and blade on ground
15 ft. (4.57 m) 2,481 (1125) 2,481 (1125)
10 ft. (3.05 m) 2,888 (1310) 2,888 (1310) 2,792 (1266) 2,792 (1266)
5 ft. (1.52 m) 5,614 (2546) 5,614 (2546) 3,425 (1554) 2,945 (1336) 2,092 (949) 1,797 (815)
Ground Line 6,223 (2823) 5,171 (2346) 3,234 (1467) 2,763 (1253) 2,027 (919) 1,734 (787)
–5 ft. (–1.52 m) 6,415 (2910) 6,415 (2910) 6,127 (2779) 5,082 (2305) 3,151 (1429) 2,683 (1217)
–10 ft. (–3.05 m) 10,613 (4814) 10,613 (4814) 6,198 (2811) 5,185 (2352)
Buckets
A full line of buckets is offered to meet a wide variety of applications. Tooth selection includes either the John Deere Fanggs ® , Standard, Tiger, Twin Tiger, Abrasion panel,
or Flare tooth, or the ESCO (Vertalok) Standard, Tiger, Twin Tiger, or Flare tooth. Replaceable cutting edges are available through John Deere parts. Optional side cutters add
6 inches (150 mm) to bucket widths.
Bucket Bucket Bucket Arm Dig Force Arm Dig Force Bucket
Type Bucket Width Capacity* Weight Dig Force 5 ft. 4 in. (1.62 m) 6 ft. 11 in. (2.12 m) Tip Radius No. Teeth
in. mm cu. yd. m 3 lb. kg lb. kN lb. kN lb. kN in. mm
Heavy-Duty 24 610 0.27 0.21 495 225 11,185 49.8 8,500 37.8 7,190 32.0 39.0 991 5
Plate Lip 30 760 0.36 0.28 522 237 11,185 49.8 8,500 37.8 7,190 32.0 39.0 991 6
36 915 0.45 0.34 544 247 11,185 49.8 8,500 37.8 7,190 32.0 39.0 991 7
Ditching 60 1525 0.75 0.57 564 256 12,465 55.4 8,845 39.3 7,435 33.1 34.1 866 0
*All capacities are SAE heaped ratings.
