PARTS LIST
MODEL 720-0138-NG
REF# DESCRIPTION Q’TY REF# DESCRIPTION QTY
1 Lid, Front 1 17 90 Degree Brass 1
2 Heat Indicator 1 18 Regulator, NG 1
3 Name Plate 1 19 Front Baffle, Front Burner 1
4 Heat Insulating Spacer 2 20 Gas Valve, Main Burner 4
5 Handle Assembly, Lid 1 21 Gas Valve, Infrared Burner 1
6 Infrared Burner 1 22 Gas Pipe 1
7 Gas Collector 1 23 Electronic Ignition 1
8 Cooking Grid with Hole 1 24 Manifold 1
9 Warming Rack 1 25 Manifold Retainer Bracket 5
10 Cooking Grid 2 26 Control Panel 1
11 Flame Tamer 4 27 Control Knob Seat 5
12 Main Burner 4 28 Control Knob 5
13 Rear Baffle, Rear Burner 1 29 Electronic Ignition Button 1
14 Flange 2 30 Lighting Rod 1
15 Bowl Assembly 1 31 Grease Tray 1
16 12” PVC Gas Hose 1
24
