Two LSS-10 and LSS-12’s with Satellite Loudspeaker System
Figure 4. Stereo/dual subwoofer application
LSS-12 Back LSS-12 Back
NOTE: ADJUST SETTING ON BOTH LSS-10 AND LSS-12 SUBWOOFER TO BE THE SAME
Optionally, you may wire
in a similar fashion, using
the speaker level inputs
and outputs.
JobSite M64
Receiver
R L
Subwoofer line input
Trigger output
Speaker left out Speaker Right out
