Basic connections, Installing your new vcr – JVC HR-A34U User Manual
Page 6
6
EN
ANT. IN
RF OUT
CH3 CH4
OUT
R
L
AUDIO
VIDEO
Basic Connections
INSTALLING YOUR NEW VCR
RF OUT
ANT. IN
(Antenna or Cable input)
75 ohm terminal
Back of VCR
Antenna or Cable
Coaxial Cable
Flat Feeder
Matching Transformer
(not supplied)
AC Power
Cord
Back of VCR
AC Outlet
RF Cable
(supplied)
Audio/Video Cable
(not supplied)
TV
CH3 CH4
