18
EN
Superimpose
This function, switchable between ON and OFF, determines
whether or not operational indicators will appear on screen.
1 2 3
4 5
0
6
7 8 9
1
2
4
3
To recall an indication
1 Press OSD.
Ⅲ All indications corresponding to the current status are
displayed for 5 seconds. After that, the counter
information and RECORD/PAUSE if in the Record
Pause mode, are left displayed on the screen.
2 Press OSD again to clear the display.
CH 125 RECORD
THU 12:00 AM PAUSE
STEREO ] SP
SAP
INDEX-1
NORM
HI–FI COUNT
–1:23:45
B E + + +
Tuned-in channel or AUX(iliary) mode
When the channel is changed, the new
channel is displayed on the screen for 5
seconds.
Operation mode
When the operation mode is changed,
the new mode is displayed — RECORD
(5 sec.), PLAY (5 sec.), FF/REW (5 sec.
when engaged from Stop mode),
RECORD PAUSE (for as long as Pause is
engaged), and ITR *:** (5 sec.).
INDEX indication
Tape speed indication
"Cassette Loaded" mark
When a cassette is loaded, the mark is
displayed for 5 seconds. It blinks when the
VCR's EJECT button is pushed.
Audio mode indications (HR-A54U only) Counter reading
ACCESS MAIN MENU
SCREEN
1
Press MENU.
ACCESS FUNCTION SET
SCREEN
2
Move the highlight bar (arrow) to "FUNCTION SET" by
pressing CH
5∞ or %fi, then press OK or .
SELECT SUPERIMPOSE SET
MODE
3
Move the highlight bar (arrow) to "SUPERIMPOSE" by
pressing CH
5∞ or %fi, then press OK or to select
the desired mode:
a– Select "ON" if you want the superimposed opera-
tional indications on the TV screen.
b– Select "OFF" if you do not want the superimposed
operational indications on the screen.
RETURN TO NORMAL
SCREEN
4
Press MENU.
%
%
FUNCTION
AUTO TIMER OFF
=SUPERIMPOSE ON
AUTO SP =EP TIMER OFF
VIDEO STABILIZER OFF
NEXT PAGE
SELECT WITH ( 5,∞) AND (OK)
PRESS (MENU) TO END
HR-A34U HR-A54U
FUNCTION
AUTO TIMER OFF
= SUPERIMPOSE ON
AUTO SP =EP TIMER OFF
VIDEO STABILIZER OFF
AUTO PICTURE ON
SELECT WITH ( 5,∞) AND (OK)
PRESS (MENU) TO END
NOTES:
● If you engage the Record Pause mode, RECORD/PAUSE is
displayed regardless of the Superimpose mode setting.
● If you select a channel on which no signal is received, the
channel number is displayed regardless of the Superimpose
mode setting.
Clock time
Stereo program indication
(HR-A54U only)
Second Audio Program indication
(HR-A54U only)
Tape position indicator
The superimposed indication on the TV screen tells you what the VCR is doing.
CH
OK
MENU
OSD
PLAYBACK AND RECORDING FEATURES (cont.)
