Page 2
Continued on Next Page
SB-F-EDG/10W3v3_INSTR_SKU# 011254
s t e P 7
Remove passenger side cargo panel by prying away from
side of vehicle and floor.
s t e P 6
Pull passenger side cargo panel away from the door jamb.
s t e P 5
Remove passenger side threshold plate.
s t e P 4
Fold passenger side rear seat forward.
Remove bolt securing seat belt at lower front of cargo
side panel.
Page 2 • JL Audio, Inc 2008
S T E P 9
Carefully pry taillight assembly out, then back, from vehicle,
releasing two alignment pins at the front edge.
Remove bulbs from assembly by turning 1/4 turn to the left.
S T E P 1 1
Unpack Stealthbox® and install mounting stud into threaded
insert so that 1/2 to 3/4 inch extends from enclosure.
S T E P 1 0
Route woofer wiring to passenger side rear of cargo area.
S T E P 8
Remove passenger side taillight assembly by removing
(2) 8mm screws.
