ENGINE

Type

John Deere PowerTech Plus diesel,

in-line, 6-cylinder

Aspiration

Variable geometry turbocharger

with air-to-air aftercooling and

exhaust gas recirculation

Engine air filter

Dual stage with engine

cooling fan aspiration

Displacement - bore

and stroke

549 cu. in. (9.0 L) - 4.66 x 5.35 in.

(118.4 x 136 mm),

824 cu. in. (13.5 L) - 5.2 x 6.5 in.

(132 x 165 mm)

Compression ratio

16:1

Fuel injection system:

High Pressure Common Rail (9.0 L only),

Electronic unit injectors (13.5 L)

Lubrication

Full-pressure, full-flow filtration

Oil filter

Replaceable cartridge style oil filter

FUEL SYSTEM

Type

Self priming

Filter system

Two stage with water separator

and service indicator light

Primary filter,

secondary filter

10 micron replaceable cartridge,

2 micron with spin-on element

ELECTRICAL SYSTEM

Alternator, batteries

200 amp, 3 – 12 volt,

(2775 total cold cranking amps)

with battery boost terminal

MODEL

9430T

9530T

9630T

ENGINE PERFORMANCE

Rated engine hp at 2100 engine rpm

425 hp (313 kW)

475 hp (349 kW)

530 hp (390 kW)

Engine hp, 97/68/EC at 2100 engine rpm

439 hp (323 kW)

491 hp (361 kW)

543 hp (499 kW)

PTO hp at 1,895 rpm

302 hp (225 kW)

TRANSMISSION

18-Speed Automatic PowerShift (18 Forward/6 Reverse)

Standard

FRONT AXLE

Equipped with AirCushion suspension system

Standard

REAR AXLE

Differential steer without outboard planetary axle

Standard

TRACK BELTS

30-inch wide belt

Standard

36-inch wide belt

Optional

HYDRAULIC SYSTEM (type)

(Closed-center, pressure/flow compensated)

Electrohydraulic selective control valves

4 base, 5th and 6th optional

Main pump, axial piston (displacement)

4.5 cu. in. (75 cm

)

4.5 cu. in. (75 cm

)

4.5 cu. in. (75 cm

)

Maximum pressure

2900 psi (20 000 kPa)

Maximum pump flow

48 gpm (182 L/min)

Available flow available at 1 SCV

30 gpm (114 L/min)

Available flow available at 2 SCVs

48 gpm (182 L/min)

3-POINT REAR HITCH WITH QUICK COUPLER

Category 4/4N with up to 15,300 lb. (6940 kg) maximum hitch-lift capacity

Optional

DRAWBAR

Category 4 Drawbar with heavy-duty hammerstrap

Optional

Category 4 Drawbar reinforcement up to 11,000 lb. (4990 kg)

Optional

Category 4 Wide-swing drawbar on rollers

Standard

Category 5 Wide-swing drawbar on rollers

Optional

Standard

Category 5 Wide-swing drawbar with bottom rollers

Optional

Category 5 Drawbar reinforcement up to 12,000 lb. (5443 kg)

Optional

Secondary chain support

Standard

PTO (Fully independent Power Take Off)

1¾-in. diameter, 20 spline, 45 mm, 1,000 rpm

Optional

CAPACITIES

Fuel tank

330 gal. (1249 L)

Cooling system

14 gal. (53 L)

Crankcase with filter

11 gal. (41.6 L)

15.8 gal. (59.8 L)

Hydraulic system with 3-point rear hitch

27 gal. (102.2 L)

Hydraulic system without 3-point rear hitch

27.5 gal. (104.1 L)

BRAKES

Hydraulic power, wet disk, self adjusting

Standard

AVERAGE BASE WEIGHT less weights, with no PTO, and no 3-point rear hitch:

Tracks

43,000 lb. (19 504 kg)

common specifications

Specifications by model – 4wD

MODEL

9230

9330

9430

9530

9630

9430 Scraper Special

9530 Scraper Special

9630 Scraper Special

ENGINE PERFORMANCE

Rated engine hp at 2,100 engine rpm

325 hp (239 kW)

375 hp (276 kW)

425 hp (313 kW)

475 hp (349 kW)

530 hp (390 kW)

425 hp (313 kW)

475 hp (349 kW)

530 hp (390 kW)

Engine hp, 97/68/EC at 2,100 engine rpm

337 hp (248 kW)

388 hp (285 kW)

439 hp (323 kW)

491 hp (361 kW)

543 hp (399 kW)

439 hp (323 kW)

491 hp (361 kW)

543 hp (399 kW)

PTO hp at 1,895 rpm

263 hp (196 kW)

320 hp (238 kW)

FINAL DRIVES

Inboard planetary

Inboard planetary with

double-reduction axle

Inboard planetary with

double-reduction axle

Inboard planetary

Inboard planetary with

double-reduction axle

Inboard planetary with

double-reduction axle

TRANSMISSIONS

18-Speed Automatic PowerShift (18 Forward/6 Reverse)

Optional

Standard

24-Speed Manual Shift (24 Forward/6 Reverse)

Standard

AXLES

100 mm x 3045 mm (120 in.)

Standard

110 mm x 3045 mm (120 in.)

Optional

Standard

120 mm x 3045 mm (120 in.)

Standard

DIFFERENTIAL LOCK

Hydraulic differential lock

Optional

Standard

HYDRAULIC SYSTEM (Closed-center, pressure/flow compensated)

Electrohydraulic selective control valves

4 standard, 5th and 6th optional

4 standard with 48 gpm (182 L/min) flow, or 4 optional with Scraper High Flow 75 gpm (283.9 L/min)

Main pump, axial piston (displacement)

4.5 cu. in. (75 cm

)

4.5 cu. in. (75 cm

)

4.5 cu. in. (75 cm

)

4.5 cu. in. (75 cm

)

4.5 cu. in. (75 cm

)

Maximum pressure

2900 psi (20 000 kPa)

Maximum pump flow with PowerShift Transmission

48 gpm (182 L/min)

Maximum pump flow with Manual Shift Transmission

44 gpm (167 L/min)

Available flow available at 1 SCV

30 gpm (114 L/min)

Available flow available at 2 SCVs with PowerShift Transmission

48 gpm (182 L/min)

Available flow available at 2 SCVs with

Manual Shift Transmission

44 gpm (167 L/min)

3-POINT REAR HITCH WITH QUICK COUPLER

Category 3/4N with up to 15,300 lb. (6940 kg)

maximum hitch-lift capacity

Optional (N/A with 100 mm axle)

Optional

Category 4/4N with up to15,300 lb. (6940 kg)

maximum hitch-lift capacity

Optional (N/A with 100 mm axle)

Optional

DRAWBAR

Category 4 Drawbar

Standard

Category 4 Heavy-duty drawbar support

Optional

Category 4 Drawbar reinforcement up to 11,000 lb. (4990 kg)

Optional

Secondary chain support

Standard

Category 5 Drawbar up to 12,000 lb. (5443 kg) not compatible

with 3-point hitch or PTO

Optional

Standard

PTO (Fully independent Power Take-Off)

1¾-in. diameter, 20 spline, 45 mm, 1,000 rpm

Optional

CAPACITIES

Fuel tank

350 gal. (1325 L)

Cooling system

12.5 gal. (47.3 L)

14 gal. (53 L)

Crankcase with filter

8.4 gal. (31.8 L)

11 gal. (41.6 L)

Hydraulic system with 3-point rear hitch

28 gal. (106 L)

Hydraulic system without 3-point rear hitch

27 gal. (102.2 L)

BRAKES

Hydraulic power, wet disk, self adjusting

on front and rear axle, plus secondary brake

Standard

Hydraulic trailer brakes

Optional

ESTIMATED SHIPPING WEIGHT for tractor equipped with standard tires, with no PTO, and no 3-point rear hitch:

4WD

32,170 lb. (14 592 kg)

34,134 lb. (15 483 kg)

35,530 lb. (16 116 kg)

36,070 lb. (16 361 kg)

37,290 lb. (16 914 kg)

35,530 lb. (16 116 kg)

36,070 lb. (16 361 kg)

37,290 lb. (16 914 kg)

Specifications by model – Tracks

All John Deere tractors come with a 24
total month/2,000 total hour factory basic
warranty. You may elect to extend your
warranty for engine and powertrain related
components through the PowerGard Protection
Plan. See your dealer for pricing and details, or
go online to

www.powergard.com.

PowerGard

™

extended warranty

protection plan

Note: Specifications and design subject to change without notice.
