JVC JLIP GV-CB3E User Manual
Page 9
EN
9
JLIP
JLIP
Rear-panel connectors
GV-CB3 Video
Capture Box
Front-panel
connectors
Core filter
Personal computer
To video input
connector
To S-Video input
connector
To JLIP
connector
To COM port
(RS-232C)
Core filter
To digital
connector
(8-pin)
Core filter
* AC adapter
(AA-V701EG/EK)
(optional)
To AC
outlet
PC connection
cable (provided)
To video output
connector
Core filter
* Connect this if you are not using batteries in
the Video Capture Box.
