Adjusting the H PHASE
1
Press and hold the [MENU] button for about 3
seconds until the LCD display shows the menu display
2
Ensure that the cursor ( J) is located on
A1: GENLOCKB, then press the control knob to display
A1A: SD H PHASEB or A1B: HD H PHASEB
3
Press the [SHUTTER] control knob to move the cursor
( J) to the currently set value, then turn the [SHUTTER]
control knob to adjust the H PHASE value
(HD: -1024 to 1023, SD: -128 to 127)
4
After the adjustment, press the control knob to move
the cursor ( J) back to A1: GENLOCKB
Memo :
● Screens 2
and
3
differ according to the Video Format of
the camera.
Adjusting SC phase (Only for SD signal)*
1
*1 This function is unavailable when connected to GY-HM790
series.
1
Turn the [SHUTTER] control knob to display
A1C: SC COARSEB
2
Press the [SHUTTER] control knob to move the
cursor ( J) to the currently set value, then turn the
[SHUTTER] control knob to adjust the SC COARSE value
(to 0
Њ, 90Њ, 180Њ or 270Њ)
3
After the coarse adjustment, press the [SHUTTER]
control knob to move the cursor ( J) back to A1C: SC
COARSE B, then press the [SHUTTER] control knob to
display A1D: SC FINEB
4
Press the [SHUTTER] control knob to move the
cursor ( J) to the currently set value, then turn the
[SHUTTER] control knob to adjust the SC FINE value
(from -128 to 127)
Memo :
● [SC COARSE] and [SC FINE] are linked. When the upper
or lower limit of [SC FINE] is exceeded, the value of [SC
COARSE] changes.
For example, when the value of [SC COARSE] is
A0ЊB and
[SC FINE] is increased, once [SC FINE] exceeds A127B,
[SC COARSE] will become A90ЊB and [SC FINE] will
become A-128B.
5
After the adjustment, press the [MENU] button to
return to the previous display
6
Press the [BARS] button to stop the color bar signal
output
1: GENLOCK
2: CABLE
Cursor
1A: SD H PHASE
0
1B: HD H PHASE
0
Setting Item
1A: SD H PHASE
127
1B: HD H PHASE
1023
Cursor
1C: SC COARSE
0
1C: SC COARSE
90
1D: SC FINE
0
1D: SC FINE
127
STR
CMP
OFF
0 dB
ALC
LUX
