1 Headphone jack
2 VIDEO/AUDIO terminal
3 MENU buttons
• MENU button
• MENU
m buttons
4 CHANNEL m buttons
5 VOLUME m buttons
6 AI ECO sensor
7 Remote control sensor
8 ON TIMER lamp
The light is switched on while
ON TIMER function is operating.
9 POWER lamp
When the Main power is on,
the light is red.
0 Main power button
MENU CHANNEL VOLUME POWER ON TIMER
EXIT VIDEO AUDIO
IN
2 1 3 4 6 7 8 0 9 5
TV buttons and parts
VIDEO AUDIO MENU CHANNEL
IN
VOLUME ON TIMER POWER
EXIT
4 5 3 1 7 9 0 8 2
