– 28 –
English
Specifications
Amplifier section
Output Power (IEC 268-3/DIN)
SUBWOOFERS:
84 W per channel, min. RMS, both channels
driven into 6
Ω
at 63 Hz with no more than
0.9% total harmonic distortion.
MAIN SPEAKERS: 20 W per channel, min. RMS, both channels
driven into 6
Ω
at 1 kHz with no more than
0.9% total harmonic distortion.
Audio input sensitivity/Impedance
(at 1 kHz, measured at MAIN SPEAKERS)
AUX:
340 mV/50 k
Ω
Audio output level
AUX:
260 mV
Digital output: CD OPTICAL DIGITAL OUTPUT
Signal wave length: 660 nm
Output level: –15 dBm to –12 dBm
Speakers/Impedance: 6
Ω
– 16
Ω
Tuner
FM tuning range:
87.50 MHz – 108.00 MHz
AM tuning range: MW: 522 kHz – 1,629 kHz
LW: 144 kHz – 288 kHz
CD player
CD Capacity:
3 CDs
Dynamic range:
85 dB
Signal-to-noise ratio:
90 dB
Wow and flutter:
Immeasurable
Cassette deck
Frequency response
Normal (type I): 50 Hz — 14,000 Hz
CrO
2
(type II):
50 Hz — 14,000 Hz
Metal (type IV): 50 Hz — 14,000 Hz (only for playback)
Wow and flutter
0.15% (WRMS)
General
Power requirement:
AC 230 V
, 50 Hz
Power consumption:
145 W (at operation)
17 W (on standby)
Dimensions (approx.): 265 mm x 335 mm x 368 mm (W/H/D)
(10
7
/
16
in. x 13
1
/
4
in. x 14
1
/
2
in.)
Mass (approx.):
10.3 kg (22.5 lbs)
Supplied accessories
See page 6.
Design and specifications are subject to change without notice.
