EN-7
Power requirement : AC 110 V to 240 V`,
50/60 Hz
Power consumption : 23 W
Output
Charge : DC 8.5 V , 1.3 A
VTR : DC 6.3 V , 1.8 A
Charging system : Constant current,
peak detection,
timer controlled
Dimensions : 140 (W) x 42 (H) x
68 (D) mm
Weight : Approx. 300 g
SPECIFICATION
Use the AC Power Adapter (connect as shown in the
illustration above).
NOTE:
The supplied AC Power Adapter/Charger features
automatic voltage selection in the AC range from
110 V to 240 V.
USING AC POWER
Core Filter
DC cord
DC OUT
terminal
AC Power Adapter/
Charger AA-V15EG
To AC outlet
