8 ◆ Infinity QPS-1 – Owner’s Manual
QPS-1
Frequency Range: 80 ~ 20,000Hz (–6dB@80Hz)
Sensitivity: 88dB spl (2.83 volts/1 meter spatially averaged)
Impedance: 8 Ω ( 5.5 min.)
Maximum Peak Output: 108dB (spl on program)
Amplifier Requirements: Suitable for use with amplifiers
10 ~ 80W (@ 8
Ω
)
Four 3 inch
Width: 11 inches
Height: 8 1 ⁄ 2 inches
Depth: 4 1 ⁄ 2 inches
Weight: 7 pounds
Declaration of Conformity
We, Infinity Systems A/S
Kongevejen 194B
DK-3460 Birkerød
DENMARK
declare in own responsibility, that the product described
in this owner’s manual is in compliance with technical
standards:
EN 50 081-1/1992
EN 50 082-1/3.1995
Steen Michaelsen
Infinity Systems A/S
Birkerød. DENMARK. 10/97
Infinity is a registered trademark of Infinity Systems, Inc.
Dolby, Pro Logic and AC-3 are registered trademarks of Dolby Laboratories.
S
PECIFICATIONS
P
ERFORMANCE
D
ATA
D
RIVE
U
NITS
D
IMENSIONS
