NS-BHDIP01 HD Radio™ Boombox, iPod/iPhone dock, and CD
www.insigniaproducts.com
Back
#
Component Description
1
AUX IN jack
Connect an external sound source, such as an MP3 player,
to this connector.
2
Headphone jack
Connect a pair of headphones (16 to 32 ohms impedance)
to this connector with a 3.5 mm plug.
3
9V DC jack
Connect the AC Adapter to this jack.
6 “C” size
-
+
-
+
-
+
-
+
-
+
-
+
