2. Installation of Imperial DS1
This section explains the installation of Imperial DS1. Refer to the manuals supplied with the
equipment for the installation of outdoor equipment such as the dish antenna. When adding new
equipment, be sure to refer to the related parts of the manual for the installation.
2.1 Connecting to Antenna and TV
2.2 Connecting to TV/VCR using SCART Support
IN FROM ANT
OUT TO ANT
SCART
TV
IRD
IN
VCR
CH4
CH3
VIDEO
OUT
VIDEO
IN
CABLE OR OFF-AIR
ANTENNA
