FRONT CASTER MOUNTING ADJUSTMENTS
WARNING
Front caster mounting adjustments MUST be performed by a qualified
technician.
REPLACING/REPAIRING FRONT CASTER TIRE/TUBE
WARNING WARNING WARNING WARNING WARNING
Replacement of front caster tire or tube MUST be performed by a quali-
fied technician.
CAUTION
As with any vehicle, the wheels and tires should be checked periodically
for cracks and wear, and should be replaced when necessary.
FIGURE 1 - INSTALLING/REPLACING SIX OR EIGHT-INCH FRONT
CASTERS AND FORKS
Fork Stem
Locknut
Dust Cover
Front Caster
and Fork
Caster Headtube
2-inch
Extension
Spacer
DETAIL "A"
SECTION 7 FRONT CASTERS
