S
PECIFICATIONS
CS 50 CS 60 CS 60R CS 60RDT CS 80R
Frequency Range 48Hz – 20kHz (±3dB) 45Hz – 20kHz (±3dB) 50Hz – 20kHz (±3dB) 50Hz – 20kHz (±3dB) 45Hz – 20kHz (±3dB)
45Hz (–10dB) 38Hz (–10dB) 40Hz (–10dB) 40Hz (–10dB) 32Hz (–10dB)
Recommended 10 – 75 watts 10 – 100 watts 10 – 100 watts 10 – 100 watts total 10 – 100 watts
Amplifier Power (50WPC)
Range
Sensitivity 87dB 88dB 88db 88dB, both 89dB
(2.83V @ 1 meter) channels driven
Nominal Impedance 8Ω 8Ω 8Ω 8Ω per input 8Ω
Crossover Frequency 2400Hz; 12dB/Octave 2,800Hz; 12dB/Octave 2,600Hz; 12dB/Octave 2,600Hz; 12dB/Octave 2,400Hz; 12dB/Octave
Low-Frequency 5-1/4" (130mm) 6-1/2" (165mm) 6-1/2" (165mm) 6-1/2" (165mm) 8" (200mm)
Driver
High-Frequency 1" (25mm) with 1" (25mm) with 1" (25mm) Dual 3/4" (19mm) 1" (25mm)
Driver(s) acoustical waveguide acoustical waveguide
External Dimensions 7-1/2" x 10" 8-1/2" x 11" 9-3/16" (Dia.) 9-3/16" (Dia.) 10-7/8" (Dia.)
(W x H) (191mm x 254mm) (216mm x 279mm) (233mm) (233mm) (275mm)
Mounting Cutout Size 6-1/8" x 8-11/16" 7-1/8" x 9-11/16" 7-7/8" (Dia.) 7-7/8" (Dia.) 9-1/2" (Dia.)
(W x H) (156mm x 221mm) (181mm x 246mm) (200mm) (200mm) (240mm)
Mounting Depth 3-3/4" (95mm) 3-7/8" (98mm) 4-1/4" (108mm) 4-1/4" (108mm) 4-1/4" (108mm)
Weight 3 lb (1.4kg) 5 lb (2.3kg) 4.5 lb (2.0kg) 4 lb (1.8kg) 5.6 lb (2.5kg)
Optional CS 50RIF IW6 RIF IW6R RIF IW6R RIF IW8R RIF
Preconstruction
Rough-In Frame
Infinity continually strives to update and improve existing products, as well as create new ones.
The specifications and construction details in this and related Infinity publications
are therefore subject to change without notice.
Declaration of Conformity
We, Harman Consumer Group International
2, route de Tours
72500 Chateau-du-Loir
France
declare in own responsibility that the products described in this
owner’s manual are in compliance with technical standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Robin Marshall
Harman Consumer Group International
Chateau-du-Loir, France 8/04
