3 CS S ERIES
I
NTRODUCTION
Infinity CS Series
The CS Series of in-wall/ceiling loudspeakers continues Infinity’s
longstanding commitment to accurate sound reproduction. All
CS Series speakers deliver uncompromised performance in any
stereo, multichannel home theater or whole-house music system.
Unpacking the Speakers
Carefully unpack the speakers. If you suspect damage from
transit, report it immediately to your dealer and/or delivery
service. Keep the shipping carton and packing materials for
future use.
P
LANNING
Y
OUR
S
YSTEM
Before deciding where to best place your speakers, survey your
room and study Figures 1 and 2.
Figure 1.
CS 50, CS 60
Template/paint shield.
Remove paint shield (inner
rectangle) at perforation.
One speaker with grille and removable logo.
Couch
Left
Front
Channel
Right
Front
Channel
Infinity Subwoofer
(optional)
Couch
Left
Front
Channel
Left
Surround
Channel Right
Surround
Channel
Right
Front
Channel
Center
Channel
Infinity Subwoofer
(optional)
Figure 2. This overhead view shows a typical home theater plan.
NOTE: Figures 1 and 2 show recommended speaker locations.
You may also follow these general placement suggestions when
installing the speakers in the ceiling.
Template/paint shield.
Remove paint shield (inner circle)
at perforation.
® ®
CS 60R/CS 60RDT/CS 80R
One speaker with grille and removable logo.
