Compositions Overture OVTR 1 – Owner’s Manual ◆ 8
J
UDGING
B
ASS
L
EVEL
...
I
MPORTANT
!
Figure 9. The OVTR 1’s fuse is
located on the rear panel next to the
AC power cord.
O
PERATING
T
HE
S
YSTEM
(
CONT
’
D
)
3. Listen to a variety of music selections and note the bass level. If you feel there is too much
bass, you can reduce it by adjusting the BASS control from the “normal” center-detent
position towards the MIN setting (see Figure 8 on previous page). Conversely, if you want
more bass output, rotate the level control towards the MAX setting.
NOTE: The amount of bass you hear will be affected by a number of different factors, including the
room’s size and shape, the construction materials used to build the room, the listener’s position
relative to the speakers, and the position of the speakers in the room. If there is too much bass, move
the speakers away from nearby walls. Conversely, if you want more bass, place the speakers closer
to the walls (also see Figure 1 on page 3).
4. For safety reasons, the side grille is bonded in place. Please do not attempt to remove.
Potential shock hazard.
R
EPLACING
T
HE
F
USE
Compositions Overture OVTR 1 speakers each use a built-in fuse to protect the subwoofer
amplifier. To replace a fuse with a new one (see enclosed spare), perform the following procedure:
1. Switch off the speaker and unplug the power cord. Then turn the speaker around to access
the fuse holder on the rear panel (refer to Figure 9 below).
2. Using a small flat-blade screwdriver, place the tip in the indent and turn the fuse cap
counterclockwise.
3. Remove the old fuse and replace it with a new one having the same value and rating,
a 2AG 3A SB 250V fuse.
Do not substitute the blown fuse with another fuse value or rating. Doing so will void
the warranty.
4. Insert the cap holding the new fuse into the holder and turn clockwise to lock it.
5. Rotate the speaker to its original position. Then plug the speaker’s AC power cord back into
the nearest AC outlet.
OVTR 1
(rear view)
MIN MAX
BASS INPUT 8 Ω – + ON / STANDBY -230V 50Hz
150W MAX
CAUTION: FOR CONTINUED PROTECTION
AGAINST RISK OF FIRE, REPLACE
ONLY WITH SAME TYPE OF FUSE:
2AG SB 250V
ATTENTION: UTILSER UN FUSIBLE DE RECHANGE
DE MEME TYPE ET CALIBRE FUSE 1.6A 250V
OVTR 1 FUSE
F U S E
F US E
FUSE T 1.6A 250V
