Invacare Articulating/Elevating Legrest User Manual
Page 2
2
FIGURE 1 - REMOVING EXISTING RATCHET ASSEMBLY
Legrest
Support Tube
Ratchet
Handle
Upper
Support
Tube
Ratchet
Handle
Upper Support
Tube
Legrest
Support Tube
Drive Link
Link Bar
ARTICULATING LEGREST
Roll Pin
Ratchet
Handle
Upper
Support
Tube
Ratchet
Body
From Support
Tube Mounting of
Legrest Assembly
Discard
Discard
RATCHET KIT WITH ROLL PIN:
ELEVATING LEGREST
DETAIL “A” - DISASSEMBLING EXISTING RATCHET KIT WITH ROLL PIN
Elevating
Support Tube
Upper
Support Tube
Ratchet
Handle
Domed
Push Cap
Snap
Ring
Ratchet
Bar
RATCHET KIT WITH SNAP RING:
ELEVATING LEGREST
ARTICULATING LEGREST
Elevating
Support Tube
Upper
Support Tube
Ratchet
Handle
Snap
Ring
Ratchet
Bar
Drive Link
Link Bar
NOTE: Domed push cap not used on articulating legrest.
