Overview of IBM Networking
CMCC Adapter Hardware
BC-244
Cisco IOS Bridging and IBM Networking Configuration Guide
78-11737-02
The Cisco 7200 series router supports online insertion and removal (OIR), which allows you to install
or remove port adapters while the system is operating.
Note In this chapter, references to Channel Port Adapter (CPA) correspond to both the ECPA and the
PCPA. Refer to the Cisco 7200 Series Port Adapter Hardware Configuration Guidelines publication
for more details.
ESCON Channel Port Adapter
An ECPA is classified as a high-speed port adapter providing a single ESCON physical channel
interface. Current Cisco 7200 configuration guidelines recommend using no more than three high-speed
port adapters in a single Cisco 7200 router.
Parallel Channel Port Adapter
A PCPA provides a single parallel channel physical interface supporting 3.0 or 4.5 Mbps data transfer
rates.
Differences Between the CIP and CPA
Table 4 illustrates the differences between the CMCC adapters.
Table 4 Differences Between the CIP and the CPA
Product Differences CIP ECPA PCPA
Router platform Cisco 7500
Cisco 7000 with
RSP7000
Cisco 7200 Cisco 7200
Channel interfaces ESCON Parallel ESCON Parallel
Maximum number of interfaces 2 1 1
Maximum memory 128 MB 32 MB 32 MB
Cisco IOS release support Cisco IOS Release 10.2
and later Cisco IOS
Release 11.3(3)T
and later Cisco IOS
Release 11.3(3)T
and later
Virtual port number 2 0 0
Channel interface state tracking
(HSRP, SNMP alerts) Yes Disabled—Use the
state-tracks-signal
command to enable Disabled—Use the
state-tracks-signal
command to enable
