Connecting a standard video device – Insignia NS-F14TV User Manual
Page 16
16
Insignia NS-F14TV 14" Flat Panel TV
www.insignia-products.com
Connecting a standard video device
If your model has audio jacks on the side, use the following illustration
to connect a standard video device to the side jacks.
Yellow
White
Headphones
Red
Yellow
(to video output)
White
Red
(to audio output)
Non-S-Video
device
