24
7
OPTIONS
D BATTERY PACK
D CHARGERS
•BC-119N DESKTOP CHARGER + AD-106 CHARGER ADAPTER
+ BC-145 AC ADAPTER
For rapid charging of battery packs. An AC adapter is sup-
plied with the charger depending on versions. Charging
time: approx. 2 hours when BP-231 is attached.
•BC-121N MULTI - CHARGER + AD-106 CHARGER ADAPTER (6 pcs.)
+ BC-157 AC ADAPTER
For rapid charging of up to 6 battery packs (six AD-106’s are
required) simultaneously. An AC adapter should be pur-
chased separately. Charging time: approx. 2 hours when
BP-231 is attached.
•BC-160 DESKTOP CHARGER + BC-145 AC ADAPTER
For rapid charging of battery packs. An AC adapter is sup-
plied with the charger depending on versions. Charging
time: approx. 2 hours when BP-231 is attached.
D BELT CLIPS
• MB-93 SWIVEL BELT CLIP
• MB-94 BELT CLIP
Exclusive alligator-type belt clip. The same as supplied with
the transceiver.
• MB-96N/96F
LEATHER BELT HANGER
D OPTIONAL UNITS
• UT-108R DTMF DECODER UNIT
Provides pager and code squelch capabilities.
• UT-109R /UT-110R* VOICE SCRAMBLER UNITS
Non-rolling type (UT-109R)/Rolling type (UT-110R)* voice
scrambler unit provides higher communication security.
*You can use the UT-110R as Non-rolling type.
D DC CABLES
• CP-17L CIGARETTE LIGHTER CABLE
Allows charging of the battery pack through a 12 V cigarette
lighter socket. (For BC-119N)
• OPC-515L/OPC-656 DC POWER CABLES
Allows charging of the battery pack using a 13.8 V power
source instead of the AC adapter.
OPC-515L: For BC-119N
OPC-656 : For BC-121N
7.4 V
BP-240 —* 2
7.4 V
Battery case for AAA
(LR03)
×
6 alkaline
980 mAh
2000 mAh
Battery pack
BP-230N
BP-232N
Voltage Capacity Battery life* 1
7.35 hrs.
15.5 hrs.
* 1 When the power save function is turned ON, and the operat-
ing periods are calculated under the following conditions;
TX : RX : standby = 5 : 5 : 90
*
2 Operating period depends on the alkaline cells used.
