Ice Frost Operator’s Manual
© 2004-2006, IMI Cornelius Inc. - 15 - Publication Number: M620919596OPR
17. Replace the tap, remembering to smear both is seating in
the bowl and the seals (J) with Food Grade Lubricant
(FIGURE 25).
FIGURE 25
18. Remove the drip tray (L1) by rotating it slightly and pulling
it outwards (FIGURE 26).
Wash all the parts carefully and reassemble it by following
the prior operations, remembering to re-insert the
condensation discharge pipe (M1) in its seating.
FIGURE 26
