Note:
1. The diagram depicts the Administrator’s Main
Screen. The User Main Screen does not show the
F4 ADM function.
2. OSD always starts in List view, with the highlight
bar at the same position it was in the last time it
was closed.
3. Only the ports that have been set accessible by
the Administrator for the currently logged in User
are visible (see
Set Accessible Ports , p. 35, for
details).
28
OSD Operation
OSD Navigation:
• To dismiss the menu, and deactivate OSD, Click
the X at the upper right corner of the OSD Window;
or press [Esc].
• To Logout, Click F8 at the top of the Main Screen,
or press [F8].
• To move up or down through the list one line at a
time, Click the Up and Down Triangle symbols (
) or use the Up and Down Arrow Keys. If
there are more list entries than what can appear on
the Main Screen, the screen will scroll.
• To move up or down through the list one screen at
a time, Click the Up and Down Arrow symbols (
), or use the [Pg Up] and [Pg Dn] keys. If
there are more list entries than what can appear on
the Main Screen, the screen will scroll.
• To activate a port, Double Click it, or move the
Highlight Bar to it then press [Enter].
• After executing any action, you automatically go
back to the menu one level above.
