Introduciton
7
2. Port LEDs – The Port LEDs are built into the Port Selection Switches. The upper ones are the On Line
LEDs; the lower ones are the Selected Port LEDs.
The On Line LEDs light ORANGE to indicate that the computer attached to the corresponding port is up
and running. If the LED is flashing, it indicates that the port is being used for cascading to another
MiniView
® Ultra + (see Two Stage Installation , p. 12).
The Selected LEDs light GREEN to indicate that the computer attached to the corresponding port is the
one that has the KVM focus. The LED is steady under normal conditions, but flashes when its port is
accessed under
Auto Scan Mode (see F7 SCAN , p. 20).
3. Reset – Use a thin object (such as the end of a paper clip, or a ballpoint pen), to press this recessed
switch in to initiate a reset of the unit. Press this briefly for a warm reset. If the switch is kept in for longer
than three seconds, a cold reset takes place.
Warm Reset: Will rescan your ports for connections.
Cold Reset: Cycles the power off and clear the internal memory.
4. Power LED – Lights to indicate that the unit is receiving power.
