Removing the disc from the cartridge

DVD-RAM media is available in bare-disc or cartridge form. To use cartridge
media in your Multi-Burner, you must first remove the disc from the cartridge.

Using the tip of a ball point pen, push and break the lock pin tab 1 . To
remove the disc, use a ball point pen to push down on the cartridge lid lock

2 and pull the cartridge lid out 3 . When the cartridge lid is open, the disc

can be removed.

Note:

The cartridge lid lock and the cartridge lid tab are located on the side of
some cartridges, as shown in 2a and 3a above.

Attention:

Do not touch the recording area of the disc when handling bare

media.

Returning the disc to the cartridge

To return the disc to the cartridge, align the label side of the disc 1 with the
DVD-RAM cartridge label side. Insert the disc and close the cartridge lid 2 .
A clicking sound will occur when the lid closed.
