Invacare Formula TRE - Manual (Page 57)

Front Rigging - Center Mount Rigging - CTMT-F/CTMT-FL
w/ FBCTMT (One PC Flip-Up Footboard)
(Before 12/10/08)
(CTMT-F = 12-1/4" - 15" Range) & (CTMT-FL = 16" - 18-3/4" Range)
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1148725 Legrest Support Assembly, Center Mount Rigging 1 1 1 A
Ring, Retainer (1/4 x 1/2 x 1/64") 1 2 2
Pin, Angle, Adjustable, ASBA 1 1 3
Bearing, Flange (1/2 x 13/16 x 1/2") 1 2 4
NLA - Support, Center Mount Rigging Legrest,
Black 1 1 5
Rack, Center Mount Rigging Angle Adjustable 1 1 6
Screw, Socket Head (5/16-18 x 1-1/2") 1 4 7
1021344 Screw, Socket Head (5/16-18 x 1-1/2") 1 4 7
1148722 Footboard Assembly, CTMTFB (For CTMT-F 12-1/4
- 15" & PCTMT 10 - 13") 1 1 8 B
1148724 Footboard Assembly, Long, CTMTFB (For
CTMT-FL 16 - 18-3/4" & PCTMT-L 14 - 17") 1 1 8 B
1144608 Kit, Heel Stop and Extension Tube Mounting
Hardware 1 1 9 C
Locknut (5/16-18) 1 2 10
Bushing, Actuator Motor (3/8 x 3/4 x 5/32") 1 4 11
Screw, Hex Head (5/16-18 x 4") 1 2 12
1153789 Bracket, Heel Stop, Black 1 2 13 F
1148711 Tube, Extension, Black 104355- Short (For CTMT-F
12-1/4" - 15" Range & PCTMT 10"-13" Range) 1 2 14 G
1148721 Tube, Extension - Long (For CTMT-FL 16" - 18-3/4"
Range & PCTMT-L 14"-17" Range) 1 2 14 G
1144607 Tube, Vertical Support with Caps 1 1 15 D
1144609 Package, End Cap (1" Square) 10 1 16
1147134 Kit, Footboard Mounting Hardware 1 1 17 E
Screw, Socket Head (3/8-16 x 2-1/2") 1 1 18
Washer, Flat (3/8 x 11/16 x 1/16") 1 1 19
Washer, Nylon (3/8 x 3/4 x 1/16") 1 2 20
Bushing (3/8 x 5/8 x 1/2") 1 1 21
Locknut, Low Profile (3/8-16) 1 1 22
Screw, Set Socket Flat Point (5/16-18 x 1") 1 1 23
Locknut (5/16-18) 1 1 24
1114311 Footboard w/ Cover (11-1/4" W x 11-1/2" L) 1 1 25
A - Includes items 2-7
B - Includes items 9, 13, 14, 15, 17 and 25
C - Includes items 10-12
D - Extension Tube and Vertical Support Tube includes Tube Caps at both ends
E - Includes items 18-24
F - Heel Stop Bracket was revised 2/6/08. It is recommended to order in pairs to match for chairs manufactured before 2/6/08.
G - End Caps are no longer used or required for the extension tube as of 4/9/08
