Reliant Scale RLS6 4 Part No 1114832
Operating the Scale
Keypad functions
NOTE: For this procedure, refer to FIGURE 3.
CAUTION
DO NOT operate keypad with pointed objects (i.e. pencils, pens, fingernails, etc.) - otherwise
damage to the key pad will result.
FIGURE 3 Operating the Scale - Keypad functions
KEY INDICATOR
DISPLAYED
INDICATOR
LOCATION
DEFINITION
ON
OFF
OFF
Center of Display
Window Pressing this key will apply power to the scale
and turn the unit on. When the scale is
already on, pressing the button will turn the
unit off.
ZERO ZERO
Lower Left Corner of
the Display Window Pressing this key when the scale is on will reset
the weight shown in the display window to zero.
UNITS
Lower Right Corner of
the Display Window The function of this key is to change the unit of
measurement from pounds (lbs) to kilograms (kg).
LOCK
UNLOCK
LOCK
Lower Right Corner
of the Display
Window This key is used to lock or unlock a weight
value in the display window.
Note: Weight displayed is a stored weight and
not the current weight when the key is used in
the lock position.
N/A LO BAT
Center of Display
Window Indicator is shown in the display window to
notify when battery is low.
ON
OFF
ZERO
Reliant Scale
Model RLS6
CAPACITY 600 LB, 272 KG
To Operate:
1. Attach sling.
2. Press ON key.
3. Press ZERO key.
4. Lift patient.
5. Press LOCK key
6. Lower Patient
7. Read Weight
UNITS
UNLOCK
ON
By
DETECTO
ZERO
LOCK
LOCK
ZERO LOCK
lb kg
WEIGHT
Display
Window
Keypad
