MDrive23 Microstepping Datasheet REV121704 5
Ш 0.97
(Ш 24.6)
Linear Actuator MDrive23
MDRIVE23 MICROSTEPPING – MECHANICAL SPECIFICATIONS
Dimensions in Inches (mm)
Rotary MDrive23: Single Shaft, Control Knob & Encoder Versions
1.63
(41.4)
2.22 SQ.
(56.4 SQ.)
1.50
(38.1)
2.92
(74.2)
1.856 ±0.008 SQ.
(47.14 ±0.2 SQ.)
4X Ш 0.205
(Ш 5.21)
0.06
(1.6)
6.00
(152.4)
1/4-20 UNC-2A
THREAD TO
WITHIN 0.05 (1.3)
OF SHOULDER
0.375
(9.52)
2.64
(67.1)
Interface
Option
P1
0.50
(12.7)
Ш 1.500 ±0.002
(Ш 38.10 ±0.05)
P2
1.63
(41.4)
2.22 SQ.
(56.4 SQ.)
1.50
(38.1)
2.92
(74.2)
1.856 ±0.008 SQ.
(47.14 ±0.2 SQ.)
4X Ш 0.197
(Ш 5.0)
0.81 ±0.02
(20.6 ±0.5)
0.59 ±0.008
(15.0 ±0.2)
0.06
(1.6)
L
MAX
L
MAX2
0.23 ±0.004
(5.8 ±0.1)
Ш 0.250 +0/-0.0005
(Ш 6.35 +0/-0.013)
Interface
Option
P2
P1
Ш 1.500 ±0.002
(Ш 38.10 ±0.05)
0.19
(4.8)
MDrive Lengths Inches (mm)
LMAX LMAX2
SINGLE SHAFT
VERSION
CONTROL KNOB or
ENCODER VERSION Stack Size
2218 2.63 (66.8) 3.35 (85.1)
2222 3.00 (76.2) 3.70 (94.0)
2231 3.86 (98.0) 4.57 (116.1)
1.20
(30.4)
1.42
(36.1)
1.90
(48.3)
Differential
Adapter
.
Control Knob 100 - 1000 Line Encoders
L
MAX2
Options
0.36
(9.1)
Interface Options
C Connector
Pluggable Clamp
Type Terminal Strip
0.44
(11.2)
Flying Leads
12.00
+1.0/-0.0
(304.8)
(+25.4/-0.0)
2.22
(56.4)
3.00
(76.2)
1.17
(29.7)
2000 Line Encoder
