Insignia NS-24FTV User Manual
Page 7
6
Insiginia NS-24FTV 24-inch Color TV
www.insignia-products.com
Back
Side
Note
The vido input for AV2, component video, and the side AV jack
cannot be used at the same time because they share the same
channel.
Note
The vido input for AV2, component video, and the side AV jack
cannot be used at the same time because they share the same
channel.
AV1input
jack
Y input jack
Video output
jack
C
b
input jack
C
r
input jack
Audio output
jacks
S-Video
input jack
Audio input
jacks
Video input
jacks
Antenna/
Cable TV
jack
L
R
Video input jack
Audio input jacks
Headphone jack
