To connect cable TV or a VHF/UHF external antenna:
1 Connect a 75 Ohm cable to the antenna jack on the back of your
TV.
2 Connect the other end of the 75 Ohm cable to cable TV or an
external VHF/UHF TV antenna.
Connecting an external audio system
Note
If you use a 300 Ohm flat feeder, you need to connect a 300/75
Ohm converter to the 300 Ohm flat feeder, then connect the
converter to your TV antenna jack.
We recommend using a 75 Ohm cable to reduce interference
caused by radio waves.
Red
White
To external input
Red
White
L audio
output
R audio
output
Video
output
Audio
system
