8
ISA Version
Installing the McPC 10/100 (ISA Version)
Offering plug-and-play operation, the McPC 10/100 comes ready to install, utilizing
power from the PC’s power supply. To install the McPC 10/100:
11. Turn off the PC
12. Remove its cover
13. Find an empty ISA slot
14. Align the McPC 10/100 in the slot
15. Screw the the McPC 10/100 into the computer casing’s bracket
16. Make sure the McPC 10/100 does not extend past the edge of the case
17. Attach the keyed mini-power connector to the McPC 10/100
18. Attach the male end of the “Y” connector to one of the computer’s standard size
power connectors
19. Replace the cover
20. Attach the cables between the McPC 10/100 and the devices that will be
interconnected
NOTE
The McPC 10/100 DOES NOT plug into the motherboard. McPC 10/100 draws
power from the computer; no additional power source is necessary.
