20
OSD Security
The OSD provides a password security in order to prevent unauthorized access to the computers. To set a password:
1. Press [F10] to bring up the SET UP menu;
2. Move the Highlight Bar to PASSWORD, then press [ENTER];
3. Key in the new password, then press [ENTER]; (the password may be up to 8 characters long, and can consist of any combination of letters and
number (A – Z, 0 – 9);
4. Key in the new password for confirmation, then press [ENTER].
If the two entries match, the new password is accepted and screen displays the following message:
SET PASSWORD OK
If the entries do not match, the screen will display:
PASSWORD NOT MATCH
You will have to start from the very beginning of the process again.
5. To modify or delete a previous password, access the Password function in steps 1 and 2, then use the backspace or delete key to erase the
individual letters or numbers.
