2 on/off diode (status display), 3 battery charger display – Invacare Electric wheelchair User Manual
Page 37
37
7.2
ON/OFF diode (status display)
INFORMATION
The ON/OFF diode (in key symbol) also serves as status or error message display. For error
codes please see chapter "Error codes and diagnostic codes" on page 46.
7.3
Battery charger display
•
All diodes illuminated: Full range
•
Only red diodes illuminated:
Reduced range
•
Both red diodes flashing:
Very low range
•
Only one red diode flashing:
Battery on reserve = Charge batteries straight away
Battery charger display
INFORMATION
Protection against total discharge: The electronic system automatically shuts actuation down
after a certain travel time on reserve battery and the wheelchair comes to a standstill.
