Ussiinngg EExxtteerrnnaall SSttrroobbeess CCoonntt..
U

Ussiinngg IIkkeelliittee N

Noonn--D

DSS SSuubbssttrroobbeess ((SSuubbssttrroobbee 5500,, 110000AA,,

220000,, 440000)) w

wiitthh tthhiiss H

Hoouussiinngg..

The Conversion Circuitry is automatically disabled when used

with a Non-DS Substrobe. These Substrobes can be used in their

manual mode utilizing any power settings provided on the

Substrobe.

Ussiinngg N

Noonn IIkkeelliittee SSttrroobbeess w

wiitthh tthhiiss H

Hoouussiinngg..

The Conversion Circuitry is automatically disabled when used

with a Non Ikelite Strobe. Non Ikelite strobes can be used in their

manual mode utilizing any power settings provided on the strobe.

SSttrroobbee AArrm

mss

This housing offers two types of arm mounting systems. The

top of the rubber handles utilize Ikelite’s Quick-Release Arm,

available with the SA-100R Arm system.

The bottom of the rubber handles have a wing nut that accepts

the Ikelite Tray Mount. The Tray Mount comes with the Ikelite

SA-125 Arm system and the SA-100T Arm system.

LLuubbrriiccaannttss

1. Ikelite provides silicone lubricant with the housing. We

recommend that you use only Ikelite lubricant as some other

brands may cause the o’ring to swell and not seal properly.

2. Use only enough lubricant to lightly cover control shafts and

o’rings. Wipe off any excess lubricant with a clean cloth.

Lubricant is not a sealant, it is used to reduce friction. Excessive

lubricant can collect sand and dirt which may interfere with

proper sealing.

CCAAU

UTTIIO

Neevveerr uussee sspprraayy lluubbrriiccaannttss aass tthhee pprrooppeellllaanntt iinnggrreeddiieenntt ccaann

caauussee tthhee ppllaassttiicc hhoouussiinngg ttoo ccrraacckk..

PPrree--D

Diivvee YYoouurr SSyysstteem

It is recommended that you take the complete system into a

swimming pool before use in open water. This will give you a

chance to become familiar with the handling and operation of

your housing and strobe(s).

Oppttiioonnaall AAcccceessssoorriieess

LLeeaadd W

Weeiigghhtt #

#00990066..5588

The buoyancy of the system will depend on the size and

number of strobes used as well as the weight of the camera.

Ideally the system should be slightly negative in the

environment in which it will be used. If you need to add weight

to the system, an optional lead weight is available. To add the

lead weight remove the (2) screws from the bottom of the

aluminum tray. Place the lead weight into the pocket of the

aluminum tray and reattach.

IIkkeelliittee LLuubbee #

#00118844..11

PPoorrtt O

O’’rriinngg #

#00110055

Hoouussiinngg BBaacckk O

O’’rriinngg #

#00113322..6611

While both the Port and Back o’rings should last quite some time

it is best to carry a spare in case one becomes damaged or lost.

Hoouussiinngg BBaacckk O

O’’rriinngg &

& PPoorrtt O

O’’rriinngg KKiitt #

#55551122..6699

LLeennss &

& PPoorrtt RReeccoom

meennddaattiioonnss

For the latest information on Lens & Port recommendations visit our

web site at www.ikelite.com or contact Ikelite.

*24-120mmD..............Not Recommended

*24-120mm IF ............Not Recommended

*28-70mmD................5503.50 ..............................................................5510.81

*28-80mm 1:3.5G ......5503.50 ..............................................................5510.81

*28-85mm ..................5503.80..............................................................5510.81

*28-100mm G ............5503.50 ..............................................................5510.81

*28-105mm D macro 5503.81 (9) ........................................................5510.81

*28-200mm................5503.80..............................................................5510.81

*35-70mm ..................5503 ..................................................................5510.81

*35-80mmD................5503.50 ..............................................................5510.81

*35-105mmD ..............5503.50 ..............................................................5510.81

*35-135mmD ..............5503.80..............................................................5510.81
(*) Zoom lenses that do not focus to 12” require a +4 diopter close-up lens

be added to the lens when used underwater behind a dome port.

(9) f3,5-4.5 “D” AF zoom needs custom zoom clamp and sleeve included

with #5503.81 port.

SSttoorriinngg tthhee H

Hoouussiinngg

When the housing is going to be stored for a prolonged period

the exterior of the housing should be soaked in a mild soap

solution, rinsed and dried thoroughly. Then remove the back and

port from the housing. Remove the back and port o’rings, lightly

lubricate them and place them in a plastic zip-lock bag. Place the

plastic bag inside the housing for storage.

CChhoooossiinngg aa PPoorrtt

MEE PPO

ORRTT 66””

#5503........Wide angle 28mm to 17mm

or lens up to 7.6cm (3") in length

#5503.20 ..Nikon 18 & 20mmD lenses

#5503.50 ..Lens 7.6-10.1cm (3-4")

#5503.55....Lens 8.9-11.4cm (3.5-4.5")

#5503.80 ..Lens 10.1-12.7cm (4-5")

#5503.81....Nikkor 28-105mm lens only

#5503.85 ..Lens 12.7-15.2cm (5-6")

SUPERWIDE DOME PORT 6”

#5503.15 ........Lens up to 6.3cm (2.5")
D

MEE PPO

ORRTT 88””

#5510.80 ..8” Dome Port (see lens & port recommendations)

Some zoom lenses may require the addition of a +diopter close-up lens.

(Available from camera store).

•With the lens on the camera extended to

full length, measure from front of camera

to face of lens.

•Select the appropriate port based on the

lens type and length.

•Maximum lens diameter accommodated is

8.4cm (3.3")

•Maximum lens diameter when using

zoom or focus clamp 7.1cm (2.8")

Measure

PPoorrtt IInnffoorrm

maattiioonn

While we have included a list of our ports and a short list of

Lenses and port recommendations we suggest visiting our web site

for the latest information on lenses and port recommendations.
