Intel Compaq nc6400 - Manual (Page 35)

Network Architecture
Models Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming IEEE 802.11 compliant roaming between access points
Output Power (for
CKK)
2
15 dBm
Output Power (for
OFDM; power varies by
data rate)
2
15 dBm
Power Consumption Transmit: 1.8 Watts (max)
Receive: 1.4 Watts (max)
Idle mode
3 : 150 mW (nominal)
Sleep mode: 30 mW (max)
Power Management ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity 4 54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm
Antenna type High efficiency dual band antenna with spatial diversity, mounted in the
display enclosure
Range 802.11 a – Typical
(@6 Mbps) 600 feet – Outdoor Open Area
150 feet – Indoor, Office environment
802.11 b – Typical
(@1 Mbps) 1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical
(@1 Mbps) 1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor PCI-Express MiniCard
Weight 0.013 lb (6 g)
Dimensions 0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
Operating Voltage 3.3v +/- 10%
Temperature Operating
Non-operating 32° to 176° F (0° to 80° C)
-40° to 176° F (-40° to 80° C)
Humidity Operating
Non-operating 10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude Operating
Non-operating 0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
Configuration Utility 5 Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Intel PROSet (required for Cisco Compatible Extensions support)
LED Activity LED Off – Radio OFF; Solid LED On – Radio ON
Check latest software/driver release for updates on supported security features. 1.
Maximum output power may vary by country according to local regulations. 2.
In Power Save Polling mode. 3.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation). 4.
WLAN supplier's client utility is required for Cisco Compatible Extensions support. WLAN
may also be compatible with certain third-party software supplicants. 5.
QuickSpecs
HP Compaq nc6400 Notebook PC
Technical Specifications
DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007 Page 35
