HP ev2200 1xEV-DO
Broadband Wireless
Module Band and Power Class 0 (North American Cellular) – Class III;
1 (North American PCS) – Class II
Wireless Protocol
Standards CDMA 1x Release 0/A;
IS-95A, IS-95B, IS-2000
Wireless Parametric
Standards Meets or exceeds TIA/EIA IS-98-D
Interoperability CDG 22 (TIA/EIA/IS-95-A)
CDG 53(TIA/EIA/IS-95-B)
C.S0031 (TIA/EIA/IS-2000)
CDG 64 (TIA/EIA/IS-2000)
C.S0032 (TIA/EIA/IS-866)
Frequency Band Dual Band: 800 MHz (Cellular) and 1900 MHz (PCS)
Data Rates (Packet
Mode) IS-856 rates up to 2.4 Mbps
IS-2000 data rates up to 307.2 kbps
Chipset and Module Qualcomm MSM6500 chipset; Sierra Wireless MC5720 module
Maximum Output
Power 24dBm (+/-1)
Power Consumption
(maximum) 500mA
Power Consumption,
Sleep Mode 1.7mA – 3.5mA
Power Management USB selective suspend
CDMA slotted mode sleep and dormant modes
Antenna Type High efficiency dual band antennae with spatial diversity, mounted in the
display enclosure
Form Factor PCI-Express MiniCard
Weight 0.35 oz (10 g)
Dimensions (Length x
Width x Thickness) 2.01 x 1.18 x 0.18 in (51 x 30 x 4.5 mm)
Voltage, Operating 3.3v +/- 10%
Temperature,
Operating (from
TIA/EIA/IS-98-D) -22° to 140° F (-30° to 60° C) (full RF performance)
-22° to 167° F (-30° to 75° C) (reduced RF performance)
Temperature, Non-
operating, 96 hours
(from MIL-STD 202
Method 108) -40° to 185° F (-40° to 85° C)
Humidity, Non-
operating 85% relative humidity for 48 hours @ 185° F (85° C) (non-condensing)
Configuration Utilities Verizon Wireless VZAccess Manager
LED Activity LED Off – Radio Off;
Solid LED On – Radio On
QuickSpecs
HP Compaq nc6400 Notebook PC
Technical Specifications
DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007 Page 30
