Intel Compaq nc6400 - Manual (Page 27)

80-GB 5400 rpm
MultiBay II Hard Drive MultiBay II Drive
Adapter Dimensions (H x W x D) 0.37 x 5.51 x 5.04 in (0.95 x 14.0 x 12.8 cm)
Weight 0.16 lb (72 g)
Drive Weight 0.22 lb (101 g)
Capacity 80 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-6
Transfer Rate Synchronous (maximum) 100 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling) Single Track 3 ms
Average 13 ms
Maximum 24 ms
Rotational Speed 5400 rpm
Logical Blocks 156,301,488
Operating Temperature41° to 131° F (5° to 55° C)
Features ATA Security
HP Biometric
Fingerprint Sensor Mobile Voltage
Operation 3.0V–3.6V Single Supply
Operating Temperature32° – 158°F (0° – 70°C)
Current Consumption
@ 3.3V Less than 70 mA peak imaging and scrolling
Less than 25 mA hardware finger detection
Advanced Power Management
High-Rate Image
Capture Up to 240 image frames /sec
ESD Resistance IEC 61000-4-2 Level 4 (±15KV)
Detection Matrix 192 x 16 Pixels
9.7 mm x 0.81 mm
500 ppi High-Resolution Images
PremierSound Audio
Hardware Implementation ADI1981HD High Definition CODEC
Volume Controls Up, down, and mute buttons
Full Duplex Yes
Sound Blaster Pro
compatible Yes
Microphone Jack Stereo or mono
Headphone/Line Out
Jack Stereo
Integrated Microphone Yes
QuickSpecs
HP Compaq nc6400 Notebook PC
Technical Specifications
DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007 Page 27
