10. Click Close to close the System Properties window. A message is
displayed, informing you that the system settings have changed.
11. Click OK to restart the computer.
Enabling DMA for Windows XP
To change the DMA parameter setting from the Windows XP desktop, do the
following:
1. Click Start --> Control Panel.
2. Click Switch to classic view.
3. Double-click System.
4. Click the Hardware tab.
5. Click the Device Manager button.
6. Click on the IDE ATA/ATAPI controller to expand the tree.
7. Double-click on the controller that corresponds to where your CD-RW is
located (Primary IDE or Secondary IDE).
8. Click on the Advanced Settings tab.
9. Select the appropriate Transfer Mode pull-down that corresponds to the
CD-RW location, (Device 0 for Master, Device 1 for Slave).
10. Select DMA if it is available.
11. Click OK.
C-2 IBM 48X/24X/48X/16X Max CD-RW/DVD-ROM Combination Drive: User’s Guide
