ITEM NO. DESCRIPTION QUANTITY
1. Headrest Reinforcement Plate 1
2. Screws 10-32 x 1/2-inch 4
3. Locknuts 4
4. Instruction Sheet 1
2
This Hole Toward
Top Of Backrest
Push Foam Down For
Assembly Procedures
Kit No. 1049522 includes the following:
Cut Out For
Visual Clarity
HOLE APPLICATIONS
A = Canyon
B = Whitmeyer
C = Otto Bock
D = Otto Bock
E = Freedom
F = Mounting Hole
G = Pindot
FIGURE 2 - HOLE APPLICATIONS
FIGURE 1 - HEADREST REINFORCEMENT PLATE INSTALLATION
