Ikelite SLR-DC Housing D700 - Manual (Page 5)

5
1
10
6
7
8
12
9
11
13
16
15
2
4
5
3
14
17
18
TTL
1 -1
-1
F
-2
-3
MAN
Back View
Lens
Release
Button
Release
Mode Dial
Viewfinder Port
1. External Strobe Connector & Cap
2. Playback Button
3. Delete Button
4. Menu Button
5. Protect Button
6. Playback, Zoom Out
7. Playback, Zoom In
8. OK button
9. AF-ON Button 10. Main Command Dial
11. Multi selector
12. Multi selector
13. Center of Multi selector
14. Multi selector
15. Flash Compensation
16. Multi Selector
17. AF Area Mode Selector
18. Info/Quick Settings
Width ................10 in. (250mm) including controls
..........................13.7 in. (348mm) with Tray and Handles
Height ..............6.9 in. (175mm) including controls
..........................7.3 in. (185mm) with Tray and Handles
Depth ................6.5 in. (165mm) including controls
Weight ..............5.6 lb. (2540g) housing only
..........................7.4 lb. (3356g) housing with tray & handles
Buoyancy ..........Neutral to slightly negative in freshwater
Size and Weight
Lid
Snap
AE/FE Lock
Mode
WB, ISO, Qual
Quick Release
Button
