Technical Specifications
Server Ports
Number
8 (1x8 console switch), 16 (2x16 console switch)
Cable Types USB and PS/2
Connectors RJ-45
Sync Types Separate horizontal and vertical
Plug and Play DDC2B
Video Resolution Local Port Maximum 1280 x 1024 @ 75 hz
Update Port
Number
1
Type Serial RS-232
Connector DB-9 Male
Local Port Sets
Number
1 (1x8 console switch), 2 (2x16 console switch)
Type PS/2, VGA and ACI (ACI port available only for User A)
Connectors 2 PS/2 MiniDIN 6, 1 hD15
Dimensions
height x width x Depth
4.45 cm x 43.18 cm x 27.94 cm 1 U form factor (1.75 in x 17.00 in x 11.00 in)
weight 3.6 kg (8 lb) without cables
heat Dissipation 92 Btu/hr
Airflow 8 CFM
Power Consumption 12.5 watts
AC-input power 40 watts maximum
AC-input voltage rating 100 to 240 V ac Autosensing
AC-input current rating 0.5 A
AC-input cable 18 AwG three-wire cable, with a three-lead IeC-320 receptacle on the power
supply end and a country or region dependent plug on the power resource end
AC-frequency 50 - 60 hz
Temperature 0° to 50° C (32° to 122° Fahrenheit) operating
-30° to 60° C (-22° to 140° Fahrenheit) transit
-20° to 60° C (-4° to 140° Fahrenheit) storage
humidity 20% to 80% noncondensing operating
5% to 95% noncondensing nonoperating
Product Safety Standards
UL 60950-1, CSA C22.2 No. 60950-1, and eN 60950-1
