3 INTERMEZZO 3.5c
For optimum performance, the center-channel speaker should be
directed toward the listening area. Since many televisions are
installed so that the center-channel speaker is well above ear
level, the Intermezzo 3.5c can be tilted downward so it’s aimed at
the listening area.
If you need to tilt the Intermezzo 3.5c, refer to Figure 3 as you
perform the following steps:
1. Open the accessory pack and locate the following items:
three feet (of different lengths), three locking nuts and one
wrench.
2. Lay the speaker upside down and locate the threaded hole on
the bottom.
3. Screw in the appropriate foot for the desired amount of tilt.
4. Tighten the nut with the enclosed wrench.
5. Carefully flip the speaker upright.
T
ILT
A
DJUSTMENT
F IGURE 3 – This cross section shows where to install a
foot on the bottom of the Intermezzo 3.5c center-channel
speaker.
