Part No. 1106665 3 Solara jr.™ Ventilator Tray
FIGURE 1 - INSTALLING THE VENTILATOR TRAY
Plug Buttons (STEP 5)
Mounting Screw (STEPS 6 and 9)
Locknut
(STEP 6)
REAR Ventilator Tray Crossmember (STEP 9)
REAR
Crossmember
(STEP 2)
Side Mounting
Screw (STEP 1)
Washer (STEP 1)
CENTER Crossmember Mounting
Screw (STEP 4)
Locknut (STEP 3)
FRONT Crossmember
CENTER Crossmember
Tilt Slide Housing (STEP 6)
UPPER Frame Tube (STEP 8)
FRONT Crossmember Mounting
Screw (STEP 3)
Locknut (STEP 4)
DETAIL “B”
DETAIL “A”
Ventilator Tray
(STEP 7)
Washer (STEP 12)
Locknut (STEP 12)
FRONT Mounting Screws (STEP 10)
FRONT Locknut (STEP 10)
CENTER Locknut (STEP 11)
CENTER Mounting
Screw (STEP 11)
CENTER Fold (STEP 7)
FRONT of
Ventilator Tray
(STEP 10)
REAR Upright
Side Mounting Screw (STEP 1)
Side Mounting
Screw (STEP 12)
Side Mounting Tab
(STEPS 7 and 12)
