User Guide XB1 COM Express Module
©EKF -6- ekf.com
XB1 COM Express Module Features
Feature Summary
Feature Summary
X
B1
Form Factor
PICMG COM Express R1.0 (COM.0), Basic Module form factor (125x95mm
2
),
Pin-out Type 2
Processor
Designed for Intel® Pentium® M Micro FC-BGA 479 processors (90nm
Dothan), maximum junction temperature 100°C
<
X
B1-060: 600MHz ULV Celeron® M (Banias 130nm), 400MHz FSB, 512KB
L2 cache, 7W
<
X
B1-100: 1.0GHz ULV Celeron® M (Dothan 373), 400MHz FSB,
512KB L2 cache, 5W
<
X
B1-140: 1.4GHz LV Pentium® M (Dothan 738), 400MHz FSB, 2MB
L2 cache, 10W
<
X
B1-200: 2.0GHz Pentium® M (Dothan 760), 533MHz FSB, 2MB L2
cache, 27W
Chipset
Intel® i915 embedded systems chipset (Alviso) consisting of:
<
82915GM Graphics/Memory Controller Hub (GMCH) with Intel®
Graphics Media Accelerator (GMA) 900
<
82801FB I/O Controller Hub (ICH6)
<
82802 Compatible Firmware Hub (FWH)
Memory
Dual 200-pin SO-DIMM socket, DDR2 533 SDRAM, 2 x 1GB maximum,
symmetric dual channel capable
Video
Up to 2048x1536 pixel 16M colours @75Hz refresh rate (analog), up to
1600 x 1200 pixel 16M colours @60Hz (digital), dual screen support
<
Dual SDVO
<
Analog VGA
<
Dual LVDS
<
TV Out
<
PEG PCI Express x 16 external graphics interface, multiplexed with
SDVO
USB
8 x USB2.0
Ethernet
PCIe to Gigabit Ethernet controller 10/100/1000Mbps
PATA (IDE)
ICH6 integrated Ultra ATA/100 I/F
SATA
4 x SATA-150
GPIO
8 GPIO lines
Sound System
AC '97 or HD Audio Azalia (external Codec)
PCI
ICH6 integrated 32-bit PCI bridge, 133MBps CPCI master
PCI Express
3-Lane PCIe if PCIe Gigabit Ethernet controller is stuffed
4-Lane PCIe (x 4 Link) w/o PCIe Gigabit Ethernet controller (stuffing option)
BIOS
Phoenix BIOS
