User Guide XB1 COM Express Module
©EKF -32- ekf.com
J-COM
J-COM is the pair of connectors which serves as interface between the XB1 COM Express Module and
the carrier board. The assembly is composed of two double-row, high speed, 0.5mm pitch plugs.
Each row has 110 leads, i.e. J-COM provides 440 contact positions in total. The COM.0 specification
assigns each row a letter A, B and C, D. For Type 1 COM Express modules, rows A and B are sufficient
(single connector, 220 leads). In addition, rows C and D (dual connector, 440 positions) are required
for extended functionality incorporated into Type 2 modules such as the XB1.
A
B
#
C
D
GND
GND
1
GND
GND
ETH_MX3- 1)
ETH_LKACT# 1)
2
IDE_D7
IDE_D5
ETH_MX3+ 1)
LPC_FRAME#
3
IDE_D6
IDE_D10
ETH_LK100# 1)
LPC_AD0
4
IDE_D3
IDE_D11
ETH_LK1000# 1)
LPC_AD1
5
IDE_D15
IDE_D12
ETH_MX2- 1)
LPC_AD2
6
IDE_D8
IDE_D4
ETH_MX2+ 1)
LPC_AD3
7
IDE_D9
IDE_D0
ETH_LKACT# 1)
LPC_DRQCOM# (LPC_DRQ0#)
8
IDE_D2
IDE_DREQ
ETH_MX1- 1)
LPC_DRQ1#
9
IDE_D13
IDE_IOW#
ETH_MX1+ 1)
CLK_33LPC (LPC_CLK)
10
IDE_D1
IDE_DACK#
GND
GND
11
GND
GND
ETH_MX0-
PWRBTN#
12
IDE_D14
IDE_IRQ
ETH_MX0+
SMB_CLK
13
IDE_IORDY
IDE_A0
+2.5V (ETH_CTREF)
SMB_DATA
14
IDE_IOR#
IDE_A1
ICH_SLP_S3# (SUS_S3#)
SMB_ALERT#
15
PCI_PME#
IDE_A2
SATA_0TP
SATA_1TP
16
PCI_GNT2#
IDE_CS1#
SATA_0TN
SATA_1TN
17
PCI_REQ2#
IDE_CS3#
ICH_SLP_S4# (SUS_S4#)
SUS_STAT#
18
PCI_GNT1#
IDE_RST#
SATA_0RP
SATA_1RP
19
PCI_REQ1#
PCI_GNT3#
SATA_0RN
SATA_1RN
20
PCI_GNT0#
PCI_REQ3#
GND
GND
21
GND
GND
SATA_2TP
SATA_3TP
22
PCI_REQ0#
PCI_AD1
SATA_2TN
SATA_3TN
23
PCI_RST#
PCI_AD3
ICH_SLP_S5# (SUS_S5#)
PWR_OK
24
PCI_AD0
PCI_AD5
SATA_2RP
SATA_3RP
25
PCI_AD2
PCI_AD7
SATA_2RN
SATA_3RN
26
PCI_AD4
PCI_CBE0#
BATLOW#
WDOGRST (WDT)
27
PCI_AD6
PCI_AD9
SATA_ACT#
AC_SDIN2
28
PCI_AD8
PCI_AD11
AC_SYNC
AC_SDIN1
29
PCI_AD10
PCI_AD13
AC_RST#
AC_SDIN0
30
PCI_AD12
PCI_AD15
