Invacare Wheelchair 3G Ranger X - Manual (Page 6)

Invacare
®
3G Ranger X
™
Power Wheelchair
Accessories and Options
Invacare Corporation www.invacare.com
USA
One Invacare Way
Elyria, OH USA
44035-4190
800-333-6900 All rights reserved. Trademarks are identified by the symbols ™ and ®. All
trademarks are owned by or licensed to Invacare Corporation unless otherwise noted.
Products designated by ASL are Manufactured by Adaptive Switch Labs, Inc.
Therafin is a registered trademark of W/R Medical Electronics Co.
Monroe is a registered trademark of Tenneco Automotive, Inc.
Specifications and prices are subject to change without notification.
©2008 Invacare Corporation
Form No. 01-006
SEATING & POSITIONING
FOR YOUR SEATING NEEDS
PLEASE REFER TO THE FOLLOWING
REHAB SEATING & POSITIONING PRODUCTS
See Price List Form 07-027
Chair Features and Options
• Independent Monroe ® shock suspension for clinical and functional comfort
• 5 MPH maximum speed - standard
• Basic switch option capability on integrated seat (ADJASBA)
• Programmable performance to meet individuals needs
• 17.5'' seat-to-floor on standard, 19.75'' & 21'' optional
• Seat location system allows for balanced weigh distribution
• Continuous tilt seat 0° - 10°
• Dynamic anti tippers
• Rigid seat pan
• Convenient rear battery access
• Group 24 battery boxes
• Arms are flip back/removable
• Adjustable depth rigging attachment 2'' {1'' increments}
• Automatic dual mode battery charger (Lester brand)
• Compact size: 25'' overall base width w/14'' x 3'' wheels
• Weight limit - Up to 400 lb
• Optional long base
Footrest Extension Range
AT5043 AT5543 1651
60HD N/A 12.25" – 16.5" 13.5" – 17.5"
70MFX 6.75" – 12.5" 4.5" – 10" N/A
70NHD N/A 10.75" – 15.75" 11.75" – 17"
70STAPER N/A 12.5" – 16.5" 13.25"–17.25"
Measured from Seat Pan to back of Footplate.
Contoura Seat Sizes
D16 D17 D18 D19 D20 D21 D22
W16 X X X X X * *
W18 X X X X X * *
W20 X X X X X X X
W22 * * X X X X X
W24 * * X X X X X
*Not available with Contoura Seat Cushion.
Back Heights
25" or 29.5"
Ranger X Specifications
* Overall Width
25" w/14" x 3" Wheel
27" w/14" x 4" Wheel
** Overall Length
29.5" Short
32.5" Long
*** Seat-to-Floor 17.5" Standard Low
19.75" Optional Medium
21" Optional Tall
Battery
Group 24 deep cycle; gel/sealed
{Not Supplied}
Weight Limit
400 lbs inclusive of add-on seat
Systems and equipment
Weight w/o Batteries 153 lbs
Shipping Weight 266 lbs {18" x 18" seat and Group 24 Batteries}
* Measurement based on wheel based on wheel base. Seat width is width picked plus 7.5" for
armrest and joystick.
** Measured from headtube to anti tipper.
*** Based on 5° tilt.
Note: All specifications and dimensions are approximate.
Weight Limit 400 Pounds
Invacare recommends all wheelchairs be fitted and programmed to the consumer under the
guidance of a healthcare professional, knowledgeable of the particular limitations of the product.
Note: All weight limits are inclusive of add-on equipment and seat systems.
Memory Card – BASIC
• Standard with All Expandable Control Systems (MPJ+, PSR+, PSF+, MK6i Display).
• Used to Back Up/Restore Programmed Settings for Only One Chair.
• May be given to user or kept with provider’s files for safe keeping.
• Does not Contain Advanced Diagnostics/Help Screens/File Structure.
• Not compatible with SPJ+ Joysticks.
• Memory Card – PROFESSIONAL
• Standard with ALL MK6i Programmers.
• Available also with USB Card Reader on Order Form.
• Contains Advanced Diagnostics, Help Screens, Software Updates, File Storage/Retrieval.
• Used to back up multiple chairs and programming settings.
• Intended for use by qualified providers only.
• Not compatible with SPJ+ Joysticks.
