( ) Standard deviation
*Testing completed in an independent test lab
PRESSURE RELIEF
Average pressure per pressure point for 10 subjects
USER-FRIENDLY CONTROLS
• Power button with LED indicator displays whether
the unit is in standby or operating mode
• Auto-firm with LED indicator inflates the mattress
to maximum firmness to facilitate patient handling
• Patient weight adjustable from 70 - 350 lbs.
• Turning intervals of 30, 60, and 90 minutes, and
a non-turning mode
• Auto -firm off will manually cancel the auto -firm
mode; auto -firm mode will automatically return
to normal operation if left unattended for 30
minutes or more
INVACARE ® TURN-Q ™ LTM
LATERAL TURNING MATTRESS
PORTABILITY
• Portable, lightweight mattress-replacement
system fits most standard hospital beds
• Control unit easily attaches to top of footboard
• CPR quick-deflate handle activates rapid
deflation of the mattress in approximately
30 seconds
SPECIFICATIONS
POWER 115 VAC, 60 Hz, 15 watts
DIMENSIONS
Standard mattress 35"W x 80"L x 11"H
Power unit 20.5"W x 10.8"L x 5.6"H
WEIGHT
Mattress 29 lbs.
Power unit 23 lbs.
Maximum patient weight 350 lbs.
SAFETY
Code approval UL544
Fire CAL 106 & 117
WARRANTY
Power unit 1-year limited
Soft goods 6-month limited
MATERIAL
Power unit Cast, machined aluminum
Therapy cover 200-denier ripstop nylon
with waterproof coating
Capillary Closure - 32 mm Hg
Scapula Sacral Trochanter
Prominence
13
(5.3)
13
(5.3)
17
(6.0)
Invacare, Yes, you can. and Turn-Q are trademarks of Invacare
Corporation.
Specifications are subject to change without notification.
© 2000 Invacare Corporation Form No. 97-35 Rev. 05/00
