R 760
R 763
ERA3YEB333V
RESISTOR, 1/16W, 33KΩ
1
R 768
ERJ2RHD132X
RESISTOR, 1/16W, 1.3KΩ
1
R 769
ERJ2RKF1102X
RESISTOR, 1/16W, 11KΩ
2
R 772
R 771
ERJ2RKF1302X
RESISTOR, 1/16W, 13KΩ
1
R 779
ERA3YEB621V
RESISTOR, 1/16W, 620Ω
1
R 793
ERJ1TYJ201U
RESISTOR, 1W, 200Ω
2
R 794
SW 5
K0ZZ00000617
SW
1
SW 6
ESD165225
SW
1
SW 7
K0D112B00071
SW
1
SW 8
EVQPLDA15
SW
2
SW 9
T 1
G5BYC0000010
TRANCE
1
X 1
H0J143500058
OSCILLATOR, 14.318MHz
1
X 2
H0J327200141
OSCILLATOR, 32.768KHz
1
X 3
H0J250500025
OSCILLATOR, 25MHz
1
X 4
H2D800400015
OSCILLATOR, 8MHz
1
X 5
H0J300500011
OSCILLATOR, 30MHz
1
ZA 1
DRHM0100ZA
SPACER
1
ZA 2
DRHM0099ZA
SPACER
1
USB PCB
C 901
EEFUD0J151ER
CAPACITOR, 6.3V, 150µF
2
C 902
CN 901
K1KA12BA0014
CONNECTOR 1
CN 902
K1FB104B0055
CONNECTOR 2
CN 903
D 901
B0KB00000044
DIODE
2
D 902
L 901
J0MAB0000116
INDUCTOR 2
L 902
L 903
J0JHC0000074
INDUCTOR 4
L 904
L 905
L 906
SW PCB
C 951
F1G1A104A014
CAPACITOR, 10V, 0.1µF
2
C 952
C 953
F1G1E103A062
CAPACITOR, 25V, 0.01µF
1
CN 952
K1KA02BA0181
CONNECTOR 1
CN 951
K1MY20BA0002
CONNECTOR 1
D 951
B3ABB0000196
DIODE
1
D 952
MA2S111-TX
DIODE
1
IC 951
C0EBE0000460
IC
1
Q 952
B1DHFB000003
TRANSISTOR 1
Q 951
UNR9214J0L
TRANSISTOR 1
R 952
ERJ2GEJ104X
RESISTOR, 1/16W, 100KΩ
1
R 951
ERJ3GEYJ101V
RESISTOR, 1/16W, 100Ω
1
R 953
ERJ6GEY0R00V
RESISTOR, 1/10W, 0Ω
1
